An elevation plate or spacer plate is often needed when installing a weatherization fitting on inward opening windows. The thickness of the sash and the distance to the window frame can vary and an elevation plate helps to mount in a neat way. Usually there is a difference of about 5-20 mm and then you need to buy corresponding elevation plates to ensure a good installation.

Elevation washers may also be needed when installing weatherization fittings for outward opening windows. For example, when you have stucco or profiles in the window sash or window sill that do not allow you to mount the weatherization fitting where you want.

Hinges with the same function as hinges with angled pins, but made of thinner material and with slightly narrower dimensions. Can also be used in combination with angled pins.

Hot-dip galvanized iron. Thickness 1mm. Diameter pin 2,5mm. Width unfolded 37mm.

Screw not included. Suitable screw no 19 or TFS 6×3/4″

Model: Aug. Stenman No. 33

Period: 1930-1970

Screw not included.

Matching screw number 8

Weatherstripping for outward opening windows in a solid classical model. Stepped opening and childproof. Nickel-plated. Screw TKFS N 3.5X16 mm for installation included. Template and simple installation instructions included.

The fitting is tested and approved childproof. Also available in untreated brass.

Tips! Sometimes one or more spacers are needed to get the right distance. See related products or ask in our shop.
